CyberPower PR1500ELCD Line-Interactive UPS, with seamless Pure Sine Wave, provides the best power protection available for office system devices including PCs, workstations, networking devices, and peripherals. It’s typically integrated in the back office, server room, and data center environment.

 The UPS can be locally managed via USB or serial ports, or remotely managed via an SNMP Card (an optional Remote Management Card), allowing administrators and users unsurpassed flexibility to remotely access each UPS through the network to perform real-time monitoring, UPS configurations, and scheduled system shutdowns by using PowerPanel Management software.

Features:

• Line-interactive UPS Topology
• Active PFC Compatible
• Automatic Voltage Regulation (AVR)
• Critical/Non-critical Load Outlets
• Surge and Spike Protection
• LCD Status Display
• USB Connectivity Port
• PowerPanel Management Software
• Tower Form Factor
• Energy Saving Technology
• Pure Sine Wave Output
• Overload Protection
• Hot-swappable Batteries
• EMI and RFI Filtration
• Detachable LCD Panel
• Emergency Power Off (EPO) Port
• SNMP/HTTP Remote Management Capability

Form Factor: Tower

UPS Topology: Line-interactive

Energy Saving Technology: GreenPower UPS Bypass Technology

Energy Star Qualified: Yes

Nominal Input Voltage ( Vac ): 230

Input Voltage Range ( Vac ): 151 - 301

Input Frequency ( Hz ): 50 ± 3 | 60 ± 3

Input Frequency Detection: Auto-sensing

Rated Input Current ( A ): 10

Input Connector Type: IEC C14

Detachable Power Cord Plug Type: AU x 1 | IEC C14 x 1

Power Cord Length: 1.83m

Capacity (VA): 1500

Capacity (Watts): 1350

On Battery Waveform: Pure Sine Wave

On Battery Voltage(s) ( Vac ): 230 ± 5%

On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%

Power Factor: 0.9

Automatic Voltage Regulation (AVR): Double Boost, Single Buck

Overload Protection: Internal Current Limiting

Outlet(s) - Total: 8

Outlet Type: IEC C13 x 8

Outlet(s) - Battery & Surge Protected: 8

Outlet(s) - Critical Load (CL): 4

Outlet(s) - Non-Critical Load (NCL): 4

Typical Transfer Time ( ms ): 4

Battery Runtime at Half Load ( min ): 17

Battery Runtime at Full Load ( min ): 4

Battery Typical Recharge Time ( Hours ): 8

Start On Battery: Yes

User-replaceable: Yes

Hot-swappable: Yes

Battery Type: Sealed Lead-acid

Battery Cartridge (RBP): RBP0023 x 1

Surge Suppression ( Joules ): 405

EMI/RFI Filtration: Yes

LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log

LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Event & Log

LED Indicators: Power On, Line Mode, Battery Mode, UPS Fault, Replace Battery

HID Compliant USB Port(s): 1

Emergency Power Off (EPO) Port: Yes

Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault

Management Cable ( pcs ): Power Cord x2 | USB Cable x1 | EPO Cable x1

Power Management Software: PowerPanel Business (Recommended)

SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205

Enclosure Construction: Metal

Dimensions: 170 x 221 x 432mm

Weight: 25.1kg

Online Thermal Dissipation ( BTU/hr ): 113

Certifications: CE | EAC | RCM

RoHS: Yes

Product Warranty Period: 3 Years

Battery Warranty Period: 2 Years

SKU PR1500ELCD

Colour Black
